KM 3034-1 - Gas cooktop


KM 3034-1
Gas cooktop with electronic functions for maximum safety and user convenience.

Price: $ 4,299.00
KM3034-1

More product information

Gas cooktop with electronic functions for maximum safety and user convenience.


  • Optimal – single-handed operation via rotary dials and QuickStart

    QuickStart

    No need to press or hold the control: convenient rotary electronic controls switch the burners on.
  • Elegant design - 806 mm wide gas on glass hob
  • Particularly versatile - 5 burners incl. 1 dual wok
  • Extremely safe – GasStop&Restart function
  • Easy cleaning – dishwasher-safe ComfortClean pot rests

Downloads - KM 3034-1

User manual & Assembly

Description Format Download
Operating instructions accessoriespdf Download
Guarantee bookletpdf Download

CAD data / BIM data

Description Format Download
3D data FBXzip Download
3D data RVTzip Download
3D data IFCzip Download
3D data RFAzip Download
3D data DWGzip Download

Installation drawings

Installation drawings

Whether you want to replace a household appliance or planning a kitchen - here you will find all the relevant installation diagrams for your Miele appliance.

If you want to download an installation diagram, please click on the appropriate image and the high-resolution version is displayed. To download, click the right mouse button and save the image on your computer.

Please note that the installation and maintenance of our equipment should only be performed by a licensed contractor. For questions, please call us and we will advise you without any obligation!

Descriptions

KM 3034-1 G (Installation drawing)

1. Front, 2. Casing depth, 3. Mains connection box with mains connection cable L = 2000 mmm, 4. Gas connection R 1/2" - ISO 7-1 (DIN EN 10226)

Images serve as examples to illustrate the product benefit. Actual feature may vary per model.
